Máy hiệu chỉnh thiết bị đo - 475HP1EKLUGMTS

Processor and Memory

Microprocessor

Memory Internal Flash

System Card

RAM

80MHz Hitachi^* SH3

32MB

1GB secure digital card

32MB

Physical

Weight

Display

Keypad

1.65lb (0,75kg) with bettary

¼ VGA (240 by 320pixels) colour, 3.5in (8,9cm) transflective display with touchscreen anti-glare coated.

25keys including 4 action keys, 12 alphanumeric key, tab key, function key, backlight key, power key and 4 curor-control (arrow) keys ; membrance degner with tactile feedback.

Power supply/charge

Bettery

Bettery Operating Time

Bettery charge option

Rechargeable Lithium-ion power modul

20 hours-continuous use

40h hours – type use

80 hours – standby mode

Input voltage 100-240VAC, 50-60Hz

Cables include with U.S., Europe, and U.K.plugs

Connection

Bettery charge

HART and Fieldbus

IrDA Port

Bluetooth

Mini DIN 6-pin jack

Three 4mm banana jacks(one connection to HART and Foundation fieldbus)

IrDA(infrared Data Access) port supporting up to 115Kbps

± 15degrees recommended maximum angle from center line

Approximately 18 in.(45,7cm) recommended maximum distance

Up to 32.8ft (10m) communication distance

Uses standard Windows drives

FCC, IC and CE approvals

Certified for use in over 60 countries

Enviromental

Usage

Battery

Charge

Storage with Batteries

Storage without Batteries

Enclosure Rating

-10^oC to 50^oC

0%-95% RH(noncondensing) for 0^oC to 50^oC

10^oC to 40^oC

-20^oC to 55^oC

-20^oC to 60^oC

IP51 (from front)

Tested to Survive a 1-meter drop test onto concrete.

Easy Upgrade Requirements

Usage

PC with internet access

CD Rom drive

IrDA port

SD Card Reader

Windows XP or Windows 7
